Open Front / Standard-Duty Series
$6,776.00
| Duty Rating | Standard-Duty |
|---|---|
| Cutting Width | 60", 72" |
| Hydraulic Flow Range | 10-25 GPM |
| Max Cutting Diameter | up to 3", up to 4" |
| Motor Style | Geroler-style hydraulic motor; right-angle gearbox |
* The manufacturer’s suggested retail price (MSRP) does not include shipping and taxes. Dealers set actual prices, including invoicing currency.
Description
Built lean and mean, the standard-duty series utilizes all the same drive and blade carrier components as our tried-and-true heavy-duty series but at a more budget-friendly cost. To make these cutters more economical, we removed the chain curtains, motor guard, and made a lighter support structure. The perfect cutter for those who do occasional clearing or have fewer demanding jobs. All standard-duty units are configured with the “open front” deck design that allows the blades to engage vegetation while the leading edge makes contact. Pound for pound, you won’t find a better value on the market.
Number of Blades
(2) 0.5 x 4 in; non-updraft
Blade Type
High-tempered non-updraft steel blades to cut and discharge material quickly.
Blade Carrier
5/16" GRD-50 spun-formed pan.
All Brush Wolf blade carriers are CNC balanced for ultra-smooth operation.
Long-Lasting Blades
The Brush Wolf industrial-strength drop-down blades are heat treated, have a milled edge, and are Supertuf coated to stand the test of time.
Premium Hydraulic Motor
We paired the top-of-the-line Eaton® Geroler-style hydraulic motor with the most dependable right-angle Omni® gearbox to achieve maximum torque and ideal blade tip speed. This easy-to-maintain and tried-and-true pairing will survive the years of abuse it will see in the field.
Motor Protection
Pressure Relief Valves: Added pressure relief valves safeguard your motor from pressure spikes and allow for a faster shutdown.
Grade-2 Shear Bolt: protects the gearbox and driveline from damage.
Gearbox Seal Protection
A welded seal guard collar prevents wire, twine, and vegetation from wrapping around and damaging the gearbox.
Ultra-Rugged Deck Frame
Here’s why our brush cutters last for life. We build each deck frame from a single piece of formed 1/4" thick heavy-duty steel, never pieced together. This means our frames are consistently better made and more durable, with the elimination of construction errors and frame failure. One-piece frames will always provide superior strength.
Clean Deck Design
Our one-piece deck frame construction creates a “clean deck” design that allows material to glide off, preventing unwanted debris buildup. (Think less mess and easier to clean.)
Seam Welding
Unlike our competitors, Brush Wolf’s deck and frame construction is fully boxed and continuously welded across each seam for an indestructible, rust-proof support structure.
Reinforced Gussets
We went above and beyond to make sure our cutters are crazy strong by adding boxed-in gusset reinforcements, extra bracing, and supports.
Powder-Coated Tough
Protected with the most durable finishing process, we powder coat every part to minimize rust, resist scratches, and prevent fading, so you get more life out of your brush cutter.
Stump Jumper
These 5/16" spun-formed pans allow the cutter to glide over stumps, roots, and rocks that may dull, chip, or damage your blades.
Blade Access Cover
Easy access to the blade bolts for quick blade replacement.
Plug + Play Ready
Everything is ready to go upon delivery with the included quick-connect couplers, 78” hydraulic hoses encased in protective wrap, and dust caps to prevent line contamination.
Lift Limit Chain
A lift limit chain has been added for your safety, which prevents the cutter from being lifting too high.
Safety Steps
Enhancing safety is our thing, so we added two non-slip, serrated metal steps for easy in and out.
Universal Quick Attach System
Time is money, so we made sure our cutters attach quickly to your machine by using the industry-standard Quick Attach system. It will only take seconds to attach/detach your machine with our universal pick-up plate.
Choose Your Color
Black, yellow, or make it your own custom color.
Parts Always Available
Brush Wolf only uses well-known industry-leading parts and components that are—and will always be—available to order 24/7 at brushwolf.com/parts or by calling 877-390-9857.
| PSI cont./int. | 3,000/3,500 |
|---|---|
| Deck Thickness | 1/4 in |
| Motor/Gearbox Coupler | Machined steel |
| Motor Protection | Pressure relief valves, GRD-2 shear bolt |
| Blade Carrier | 5/16" GRD-50 spun-formed pan |
| Blade Rotation | Counterclockwise |
| Blades | (2) 0.5 x 4 in; non-updraft |
